AH180 datasheet, switch equivalent, Diodes Incorporated

AH180 Features and benefits

* Omnipolar (North or South pole) Operation
* Micropower Operation
* Single Open Drain Output
* 2.5V to 5.5V Operating Voltage
* Chopper Stabilized De.

AH180 Application

requiring specific change control (i.e. parts qualified to AEC-Q100/101/200, PPAP capable, and manufactured in IATF 1694.

AH180 Description

The AH180 is a micro-power Omnipolar Hall-Effect switch designed for portable and battery powered equipment such cellular phones, PDAs and portable PCs. Based on two Hall-Effect plates and a chopper stabilized architecture the AH180 provides a reliab.

Image gallery
