BAV5004WS Datasheet, Diode, Diodes

BAV5004WS Features

• Diode
• Fast Switching Speed: 50ns Maximum
• 400V High Reverse Breakdown Voltage Rating
• Low Capacitance: 2.5pF Maximum
• Surface Mount Package Ideally Suited

PDF File Details

Part number:

BAV5004WS

Manufacturer:

DIODES ↗

File Size:

162.09kb

Download:

📄 Datasheet

Description:

High voltage switching diode.

BAV5004WS Application

• Applications shall assume all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on D
