DXT13003EK Datasheet, Transistor, Diodes

DXT13003EK Features

• Transistor
• BVCEO > 460V
• BVCES > 700V
• BVEBO > 9V
• IC = 1.5A high Continuous Collector Current
• Totally Lead-Free & Fully RoHS compliant (Notes 1 & 2)

PDF File Details

Part number:

DXT13003EK

Manufacturer:

DIODES ↗

File Size:

308.49kb

Download:

📄 Datasheet

Description:

Npn high voltage power transistor.

DXT13003EK Application

• Applications the appropriate industry sector guidelines should be considered with regards to creepage and clearance distances between device Termin
