EM56200A

TINY CONTROLLER-BASED DUALCHANNELSPEECHSYNTHESIZER

ELAN Microelectronics Corp

EM56200A Features

* TOTAL ROM(bits) PROGRAM ROM(bits) RAM(nibbles) PORT1 [input](pins) PORT2 [I/O](pins) PORT3 [I/O](pins) VO(pins) EM56001A EM56101A EM56200A EM56300A EM56400A EM56500A EM56600A 10K x 10 16K x 10 32K x 10 64K x 10 128K x 10 256Kx10 512Kx10 8K x 10 32K x 10 32 64 128 4 2 4 4 1 2

* Single power

EM56200A General Description

EM56000A is a series of single chip dual channel IC with voice synthesizer. The dual channel can be (voice + voice) simultaneously. That contains some input and I/O ports, and a tiny controller. By programming through the tiny controller, user's application including section combination, trigger mod.

EM56200A Datasheet (202.93 KB)

EM56200A Datasheet Preview — Preview of EM56200A PDF

Datasheet Details

Part number:

EM56200A

Manufacturer:

ELAN Microelectronics Corp

File Size:

202.93 KB

Description:

Tiny controller-based dualchannelspeechsynthesizer.
