OM9553SP 5V Input / 3A Output Current +3.3V / +2.5V +1.8V / +1.5V Output Switching Regulator Three Terminal Package

The OM955X series of Switching Regulators are designed for pin compatibility with standard 3Pin linear regulators. They are well suited for on-board, non- isolated power applications where efficient point- of- load regulation is needed. The package is designed using Chip- on * Board technolo.

OM9553SP Features

* High Efficiency

* Internal Short Circuit Protection

* Small Footprint

* High Power Density- 60W/in.3 APPLICATIONS

* High Power 5V to 3.3V Regulation

* Low Voltage Battery regulation

* Embedded Processor Power

* General Purpose Low Vo

OM9553SP_ETC.pdf

OM9553SP Datasheet Preview — Preview of OM9553SP PDF

Datasheet Details

Part number:

OM9553SP

Manufacturer:

ETC

File Size:

178.30 KB

Description:

5v input / 3a output current +3.3v / +2.5v +1.8v / +1.5v output switching regulator three terminal package.
