SI-8090JF - Full-Mold / Separate Excitation Switching

SI-8090JF Description

qSI-8000JF Series SI-8000JF Series Full-Mold, Separate Excitation Switching Type s.

SI-8090JF Features

* Compact full-mold package (equivalent to TO220) Output current: 1.5 A High efficiency: 79 to 91% Requires only 4 external components Phase correction and output voltage adjustment performed internally Choke coil size can be reduced through the employment of high frequency (125 kHz) design

SI-8090JF Applications

* Power supplies for telecommunication equipment
* Onboard local power supplies sLineup Part Number VO (V) IO (A) SI-8015JF 1.59 SI-8025JF 2.5 SI-8033JF 3.3 1.5 SI-8050JF 5.0 SI-8090JF 9.0 SI-8120JF 12.0 sAbsolute Maximum Ratings Parameter DC Input Voltage Power Dissipation Junctio

📥 Download Datasheet

Preview of SI-8090JF PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
SI-8090JF
Manufacturer
ETC
File Size
87.47 KB
Datasheet
SI-8090JF_ETC.pdf
Description
Full-Mold / Separate Excitation Switching
