EL5181C, 8ns High-Speed Comparator

EL5181C EL5181C 8ns High-Speed Comparator .
The EL5181C comparator is designed for operation in single supply and dual supply applications with 5V to 12V between VS+ and VS-.

datasheet Preview Page 1 from Datasheet4u.com

EL5181C_ElantecSemiconductor.pdf

EL5181C Datasheet Preview — Preview of EL5181C PDF

Datasheet Details

Part number:

EL5181C

Manufacturer:

Elantec Semiconductor

File Size:

106.99 KB

Description:

8ns High-Speed Comparator

Features

* 8ns Typ. Propagation Delay 5V to 12V Input Supply +2.7V to +5V Output Supply True-to-ground Input Rail-to-rail Outputs Active Low Latch Dual Available (EL5281C) Window Comparator (EL5283C) Quad Available (EL548

Applications

* with 5V to 12V between VS+ and VS-. For single supplies, the inputs can operate from 0.1V below ground for use in ground sensing applications. The output side of the comparator can be supplied from a single supply of 2.7V to 5V. The rail-to-rail output swing enables direct connection of the comparat
