EL2004 Datasheet, Buffer, Elantec

EL2004 Features

• Buffer        Slew rate 2500 V ms Rise time 1 ns Bandwidth 350 MHz ELH0033 pin compatible g 5 to g 15V operation 100 mA output current MIL-STD-883B Rev C devices manufactured in U S A

PDF File Details

Part number:

EL2004

Manufacturer:

Elantec

File Size:

272.37kb

Download:

📄 Datasheet

Description:

350 mhz fet buffer. The EL2004 is a very high-speed FET input buffer line driver designed for unity gain applications at both high current (up to 100 mA)

EL2004 Application

• Applications at both high current (up to 100 mA) and at frequencies up to 350 MHz The 2500 V ms slew rate and wide bandwidth ensures the stability o
