LPS103-M - AC-DC / 136W - 260W Medical

This page provides the datasheet information for the LPS103-M, a member of the LPS103-M_lps100-m_1226382148 AC-DC / 136W - 260W Medical family.

Datasheet Summary

Features

  • Medical and ITE safeties Active power factor correction 2” x 4” footprint Less than 1U high EN61000-3-2 compliant Remote sense Power fail Adjustable main output Built-in Class B EMI filter Overvoltage protection Overload protection Thermal overload protection Isolated12 V Fan output LPX50 Enclosure kit available Electrical Specifications Input.

📥 Download Datasheet

Datasheet preview – LPS103-M

Datasheet Details

Part number LPS103-M
Manufacturer Emerson
File Size 660.18 KB
Description AC-DC / 136W - 260W Medical
Datasheet download datasheet LPS103-M Datasheet
Additional preview pages of the LPS103-M datasheet.

📁 Similar Datasheet

  • LPS100A-6 - LED Backlight Power Control (Optillis)
  • LPS100A-7 - LED Backlight Power Control (Optillis)
  • LPS1100 - Power Resistor (Vishay)
  • LPS-100 - 100W Single Output without PFC Function (Astr)
  • LPS-785-FC - Laser Diode (ETC)
  • LPS001D - MEMS Pressure Sensor (ST Microelectronics)
  • LPS200 - HIGH PERFORMANCE LOW NOISE PHEMT (Filtronic Compound Semiconductors)
  • LPS200P70 - PACKAGED LOW NOISE PHEMT (Filtronic Compound Semiconductors)
  • LPS22DF - Low-power and high-precision MEMS nano pressure sensor (STMicroelectronics)
  • LPS22HB - MEMS nano pressure sensor (STMicroelectronics)
Other Datasheets by Emerson

Full PDF Text Transcription

Click to expand full text
Embedded Power for Business-Critical Continuity LPS100-M Series 150 Watts Total Power: Input Voltage: # of Outputs: 80 - 150 Watts 90 - 264 Vac Single Rev. 4.30.09_29 LPS100-M Series  of 3 Special Features • • • • • • • • • • • • • • Medical and ITE safeties Active power factor correction 2” x 4” footprint Less than 1U high EN61000-3-2 compliant Remote sense Power fail Adjustable main output Built-in Class B EMI filter Overvoltage protection Overload protection Thermal overload protection Isolated12 V Fan output LPX50 Enclosure kit available Electrical Specifications Input Input ra­nge: Frequency: Inrush current: Efficiency: EMI/RFI: Safety ground leakage current: 90 - 264 Vac; 120 - 300 Vdc 47-63 Hz 50 A max.
