MM74HC4050 Hex Logic Level Down Converter

The MM74HC4049 and the MM74HC4050 utilize advanced silicon-gate CMOS technology, and have a modified input protection structure that enables these parts to be used as logic level translators which will convert high level logic to a low level logic while operating from the low logic supply. For examp.

MM74HC4050 Features

* s Typical propagation delay: 8 ns s Wide power supply range: 2V

* 6V s Low quiescent supply current: 20 µA maximum (74HC) s Fanout of 10 LS-TTL loads Ordering Code: Order Number MM74HC4049M MM74HC4049SJ MM74HC4049MTC MM74HC4049N MM74HC4050M MM74HC4050SJ MM74HC4050MTC MM74HC4050N Package Numbe
