MM74HC4020 - 14-Stage Binary Counter

National Semiconductor

MM74HC4020 Datasheet Preview — Preview of MM74HC4020 PDF

Datasheet Details

Part number	MM74HC4020
Manufacturer	National Semiconductor ↗
File Size	248.70 KB
Description	14-Stage Binary Counter
Datasheet	MM74HC4020-NationalSemiconductor.pdf

MM74HC4020 Product details

Description

The MM54HC4020 MM74HC4020 MM54HC4040 MM74HC4040 are high speed binary ripple carry counters These counters are implemented utilizing advanced silicongate CMOS technology to achieve speed performance similar to LS-TTL logic while retaining the low power and high noise immunity of CMOS The ’HC4020 is a 14 stage counter and the ’HC4040 is a 12stage counter Both devices are incremented on the falling edge (negative transition) of the input clock and all their outputs are reset to a low level by appl

Features

Y Y Y Y Y Typical propagation delay 16 ns Wide operating voltage range 2.
6V Low input current 1 mA maximum Low quiescent current 80 mA maximum (74HC Series) Output drive capability 10 LS-TTL loads Connection Diagrams Dual-In-Line Packages ’HC4020 TL F 5216.
1 ’HC4040 TL F 5216.
3 Order Number MM54HC4020 4040 or MM74HC4020 4040 C1995 National Semiconductor Corporation TL F 5216 RRD-B30M105 Printed in U S A http://www. Datasheet4U. com Absolute Maximum Ratings (No.
