GS82582DT21GE Datasheet, Sram, GSI Technology

GS82582DT21GE Features

• Sram
• For use with GSI FPGA-based Controller IP
• 3.0 Clock Latency
• Simultaneous Read and Write SigmaQuad™ Interface
• JEDEC-standard pinout and package

PDF File Details

Part number:

GS82582DT21GE

Manufacturer:

GSI Technology

File Size:

301.67kb

Download:

📄 Datasheet

Description:

288mb sigmaquad-ii+ sram. Table Symbol Description Type Comments SA Synchronous Address Inputs Input   – R Synchronous Read Input Active L

GS82582DT21GE Application

• Applications where alternating reads and writes are needed. Therefore, the SigmaQuad-II+ SRAM interface and truth table are optimized for alternatin
