HM74HC595 8-Bit Shift Registers

The HM74HC595 high speed shift register utilizes advanced silicon-gate CMOS technology. This device possesses the high noise immunity and low power consumption of standard CMOS integrated circuits, as well as the ability to drive 15 LS-TTL loads. This device contains an 8-bit serial-in, parallel-out.

HM74HC595 Features

* Low quiescent current: 80µA maximum

* Low input current: 1µA maximum

* 8-bit serial-in, parallel-out shift register with storage

* Wide operating voltage range: 2V

* 6V

* Cascadable

* Shift register has direct clear

* Guaranteed shift frequency: DC to 30 MHz

HM74HC595-HMSemiconductor.pdf

HM74HC595 Datasheet Preview — Preview of HM74HC595 PDF

Datasheet Details

Part number:

HM74HC595

Manufacturer:

H&M Semiconductor

File Size:

621.94 KB

Description:

8-bit shift registers.
