CS10J65A0-G Datasheet, Mosfet, HUAJING MICROELECTRONICS

CS10J65A0-G Features

• Mosfet l Fast Switching l Low Gate Charge l Low Reverse transfer capacitances l 100% Single Pulse avalanche energy Test l Halogen Free Applications： l Power switch circuit of adaptor and char

PDF File Details

Part number:

CS10J65A0-G

Manufacturer:

HUAJING MICROELECTRONICS

File Size:

405.68kb

Download:

📄 Datasheet

Description:

Silicon n-channel power mosfet. CS10J65 A0-G, the silicon N-channel Enhanced MOSFETs, is obtained by the super junction technology which reduces the conduction loss

CS10J65A0-G Application

• Applications l Power switch circuit of adaptor and charger. Absolute（Tc= 25℃ unless otherwise specified）： Symbol Parameter VDSS ID IDMa1 VGS EAS
