HD61202U

Dot Matrix Liquid Crystal GraphicDisplay Column Driver

Hitachi Semiconductor

HD61202U Features

* Dot matrix liquid crystal graphic display column driver incorporating display RAM

* RAM data direct display by internal display RAM  RAM bit data 1: On  RAM bit data 0: Off

* Internal display RAM address counter preset, increment

* Display RAM capacity: 512 bytes

HD61202U General Description

HD61202U is a column (segment) driver for dot matrix liquid crystal graphic display systems. It stores the display data transferred from a 8-bit micro controller in the internal display RAM and generates dot matrix liquid crystal driving signals. Each bit data of display RAM corresponds to on/off st.

HD61202U Datasheet (199.80 KB)

HD61202U Datasheet Preview — Preview of HD61202U PDF

Datasheet Details

Part number:

HD61202U

Manufacturer:

Hitachi Semiconductor

File Size:

199.80 KB

Description:

Dot matrix liquid crystal graphicdisplay column driver.
