HT16220 Datasheet, Controller, Holtek Semiconductor Inc

HT16220 Features

• Controller
• Operating voltage: 2.7V~5.2V
• External Crystal 32.768kHz oscillator
• 1/4 bias, 1/8 duty, frame frequency is 64Hz
• Max. 32´8 patterns, 8 commons, 32

PDF File Details

Part number:

HT16220

Manufacturer:

Holtek Semiconductor Inc

File Size:

251.12kb

Download:

📄 Datasheet

Description:

Ram mapping 32 x 8 lcd controller. HT16220 is a peripheral device specially designed for I/O type MCU used to expand the display capability. The max. display segment of
