Integrated Device Technology, Inc.
FAST CMOS 16-BIT BIDIRECTIONAL TRANSCEIVERS
IDT54/74FCT16245T/AT/CT/ET IDT54/74FCT162245T/AT/CT/ET
IDT54/74FCT166245T/AT/CT IDT54/74FCT162H245T/AT/CT/ET
FEATURES:
DESCRIPTION:
• Common features:
The 16-bit transceivers are built using advanced dual metal
– 0.5 MICRON CMOS Technology
CMOS technology. These high-speed, low-power transceiv-
– High-speed, low-power CMOS replacement for
ers are ideal for synchronous communication between two
ABT functions
busses (A and B). The Direction and Output Enable controls
– Typical tSK(o) (Output Skew) < 250ps
operate these devices as either two independent 8-bit trans-
– Low input and output leakage ≤ 1µA (max.)
ceivers or one 16-bit transceiver.
