LD1207 - 12/9 Segment Output Lines

IK Semiconductor

📥 Download Datasheet

LD1207 Datasheet Preview — Preview of LD1207 PDF

Datasheet Details

Part number	LD1207
Manufacturer	IK Semiconductor
File Size	189.47 KB
Description	12/9 Segment Output Lines
Datasheet	LD1207_IKSemiconductor.pdf

LD1207 Product details

Description

LD1207 The LD1207 is specifically designed for LED and LED DISPLAY derivers.The LD1207 have 12/9 segment output lines, 7 to 4 grid output lines, one display memory, control circuit and 3 line serial data interface.This function are all incorporated into a single chip to build a highly reliable peripheral device for a single chip microcomputer.It is very convenience to control for numeric display.LD1207’s pin assignments and application circuit are optimized for easy PCB Layout and cost sav

Features

CMOS Technology.
Segment output line selection by command : 12 ~ 9.
Grid output line selection by command : 7 ~ 4.
Operation voltage : 5V.
Low Power Consumption.
8-Step Dimming control by command.
Serial Interface for Clock, Data Input, Strobe Pins.
24-pin, SOP Package.
