IS46LR32200C, 512K x 32Bits x 4Banks Mobile DDR SDRAM

IS43/46LR32200C 512K x 32Bits x 4Banks Mobile DDR SDRAM .
The IS43/46LR32200C is 67,108,864 bits CMOS Mobile Double Data Rate Synchronous DRAM organized as 4 banks of 524,288 words x 32 bits.

IS46LR32200C-ISSI.pdf

IS46LR32200C Datasheet Preview — Preview of IS46LR32200C PDF

Datasheet Details

Part number:

IS46LR32200C

Manufacturer:

ISSI

File Size:

1.17 MB

Description:

512K x 32Bits x 4Banks Mobile DDR SDRAM

Features

* JEDEC standard 1.8V power supply.
* VDD = 1.8V, VDDQ = 1.8V
* Four internal banks for concurrent operation
* MRS cycle with address key programs - CAS latency 2, 3 (clock) - Burst length (2, 4, 8, 16) - Burst type (sequential & interleave)
* Fully differenti

Applications

* where the failure or malfunction of the product can reasonably be expected to cause failure of the life support system or to significantly affect its safety or effectiveness. Products are not authorized for use in such applications unless Integrated Silicon Solution, Inc. receives written assurance
