IS61QDPB22M36C1

72Mb QUADP Synchronous SRAM

IS61QDPB22M36C1 Features

* 2Mx36 and 4Mx18 configuration available.

* On-chip Delay-Locked Loop (DLL) for wide data valid window.

* Separate independent read and write ports with concurrent read and write operations.

* Max. 450 MHz clock for high bandwidth

* Synchronous pipeline read with EARLY write ope

IS61QDPB22M36C1 General Description

at page 6 for each ODT option. DESCRIPTION The IS61QDPB22M36C/C1/C2 and IS61QDPB24M18C/C1/ -C2 are 72Mb synchronous, high-performance CMOS static random access memory (SRAM) devices. These SRAMs have separate I/Os, eliminating the need for high-speed bus turnaround. The rising edge of K clock init.

IS61QDPB22M36C1 Datasheet (756.28 KB)

Preview of IS61QDPB22M36C1 PDF

Datasheet Details

Part number:

IS61QDPB22M36C1

Manufacturer:

ISSI

File Size:

756.28 KB

Description:

72mb quadp synchronous sram.
