BTT3050EJ Datasheet - Infineon

Smart low-side power switch

BTT3050EJ Features

* Single channel device optimized for 24 V applications

* Electrostatic discharge protection (ESD)

* Overcurrent, active clamping and overtemperature protection

* Overtemperature latch shutdown

* Supply pin undervoltage protection

* Dedicated status si

BTT3050EJ General Description

BTT3050EJ is a 50 mΩ single channel smart low-side power switch within a PG-TDSO-8 package providing embedded protective functions. The power transistor is built by a N-channel vertical power MOSFET. BTT3050EJ is monolithically integrated, automotive qualified and optimized for 24 V automotive appli.

BTT3050EJ Datasheet (1.59 MB)
