IRSM515-015, IRSM505-015 Datasheet - International Rectifier

IRSM515-015 Integrated Power Module - IPM

IRSM505-015 and IRSM515-015 are 3-phase Integrated Power Modules (IPM) designed for advanced appliance motor drive applications such as energy efficient fans and pumps. These advanced IPMs offers a combination of low RDS(on) Trench FREDFET technology and the industry benchmark half-bridge high volta.

IRSM515-015 Features

* 500V 3-phase inverter including high voltage gate drivers

* Integrated bootstrap functionality

* Low 6.0Ω (max, 25°C) RDS(on) Trench FREDFET

* Under-voltage lockout for all channels

* Matched propagation delay for all channels

* Temperature feedback

IRSM505-015-InternationalRectifier.pdf

IRSM515-015 Datasheet Preview — This datasheet PDF includes multiple part numbers: IRSM515-015, IRSM505-015. Please refer to the document for exact specifications by model.
