EL5027 Datasheet, Buffer, Intersil Corporation

EL5027 Features

  • Buffer
  • SIx inverting/non-inverting channels
  • 3.3V input logic
  • 18V output
  • 250µA typical supply current
  • Drives up to 500pF
  • TR/TF = 35ns

PDF File Details

Part number:

EL5027

Manufacturer:

Intersil Corporation

File Size:

365.63kb

Download:

📄 Datasheet

Description:

Rail-to-rail input-output buffer. CONDITION POWER SUPPLY IS IS_DIS VLR VHR VH-VL INPUT Supply Current Supply Current - Disabled VL Range VH Range Maximum VH - VL R

Datasheet Preview: EL5027 📥 Download PDF (365.63kb)
Page 2 of EL5027 Page 3 of EL5027

EL5027 Application

  • Applications
  • LTPS LCD clock drivers
  • CCD driving
  • Level shifters Ordering Information PART NUMBER EL5001IL PACKAGE 20
