ISL706CEH, ISL705ARH - 5.0V/3.3V u-Processor Supervisory Circuits

Intersil

Datasheet Details

Part number: ISL706CEH, ISL705ARH
Manufacturer: Intersil
File Size: 955.57 KB
Datasheet: ISL705ARH_Intersil.pdf
Description: 5.0V/3.3V u-Processor Supervisory Circuits
Note: This datasheet PDF includes multiple part numbers: ISL706CEH, ISL705ARH.
Please refer to the document for exact specifications by model.

3 3. Timing Diagrams. .. ..

▪ Electrically screened to SMD 5962-11213 ▪ QML qualified per MIL-PRF-38535 requirements ▪ Precision supply voltage monitor.
4.65V threshold in the ISL7x5AxH/BxH/CxH.
3.08V threshold in the ISL7x6AxH/BxH/CxH ▪ 200ms (typ) reset pulse width.
Active high, active low, and open-drain options ▪ Independent watchdog timer with 1.6s (typ) timeout ▪ Precision threshold detector.
1.25V threshold in the ISL7x5AxH/BxH/CxH.
0.6V threshold in the ISL7x6AxH/BxH/CxH.
