K2200S

Sidac

Image Manufacturer B2B MPN Description Distributor Stock Quantity Price Buy Now
part Littelfuse Inc K2200S DIAC/SIDAC 205-230V 1A DO-214 DigiKey 0 5000 units
$0.41

K2200S Datasheet (182.31 KB)

Preview of K2200S PDF

Datasheet Details

Part number:

K2200S

Manufacturer:

JIEJIE

File Size:

182.31 KB

Description:

Sidac.

K2200S Features

* Excellent capability of absorbing transient surge

* Quick response to surge voltage (ns Level)

* Glass-passivated junctions

* High voltage lcmp ignitors ABSOLUTE MAXIMUM RATINGS (TA=25ºC, RH=45%-75%, unless otherwise noted) Parameter Symbol Sto

K2200S General Description

The sidac is a silicon bilateral voltage triggered switch with greater power-handling capabilities than standard diacs. Upon application of a voltage exceeding the sidac breakover voltage point, the sidac switches on through a negative resistance region to a low on-state voltage. Conduction continu.
