JW5222 Datasheet, converter equivalent, JoulWatt

JW5222 Features

  • Converter 2.5V to 6V operating input range Up to 2.5A output current Up to 94% peak efficiency High efficiency at light load Internal Soft-Start 1MHz switching frequency Input under voltage locko

PDF File Details

Part number:

JW5222

Manufacturer:

JoulWatt

File Size:

1.15MB

Download:

📄 Datasheet

Description:

1mhz synchronous step-down converter. The JW®5222 is a current mode monolithic buck switching regulator. Operating with an input range of 2.5V-6V, the JW5222 delivers 2.5A

Datasheet Preview: JW5222 📥 Download PDF (1.15MB)
Page 2 of JW5222 Page 3 of JW5222

JW5222 Application

  • Applications 5V or 3.3V Point of Load Conversion Set Top Boxes Telecom/Networking Systems Storage Equipment GPU/DDR Power Supply TYPICAL APPLICATIO
