KSM-904TM1N Datasheet - KODENSHI KOREA CORP

KSM-904TM1N Optic receiver module

1) Transmitter(IRED) drive current : IFP = 300mAP-P ~ 600mAP-P 2) R-C Decoupling Filter with Lower Cut-off Frequency : R=100 *Ù , C=47 *Þ : 10k *Ù over ¢¡ fc = 1/2 *ð RC = 33.9Hz 3) External pull-up resistor(optional) Vcc C Rp micom GND 2/2 .

KSM-904TM1N Features

* ¤ýWide angle design ¤ýSupply-voltage range : 4.5V to 5.5V ¤ýShielded against electrical field disturbance ¤ýEnhanced immunity against ambient light disturbances ¤ýEnhanced reception distance ¤ýContinuous data transmission possible (NRZ 1000 bit/s) ¤ýAvailable for carrier frequencies between 32.7KHz

KSM-904TM1N Datasheet (233.56 KB)
