LB043WQ1-TD07 - LCD

LB043WQ1-TD07 Datasheet Preview — Preview of LB043WQ1-TD07 PDF

Datasheet Details

Part number	LB043WQ1-TD07
Manufacturer	LG
File Size	1.05 MB
Description	LCD
Datasheet	LB043WQ1-TD07_LG.pdf

LB043WQ1-TD07 Product details

Description

Interface Connection Absolute Maximum Ratings Electrical Characteristics Optical Characteristics Mechanical Characteristics Color Input Data Reference Reliability Test Outline Dimension International Standard Packing Precautions Page 3 4 6 8 9 15 18 19 20 21 22 23 25 Ver 1.0 Oct.29. 2008 2 / 26 Datasheet pdf - http://www.DataSheet4U.net/ www.DataSheet.co.kr LB043WQ1 Liquid Crystal Display Product Specification RECORD OF REVISIONS Revision No Revision Date 1.0 Oct.29. 2008 Page Final

Features

High Brightness & Contrast ratio.
Wide Viewing Angle.
WQVGA(480X272 pixels) resolution.
8 Bits color depth.
T-Con & Power Block is integrated In D-IC.
Low power consumption.
DE (Data Enable) Only mode.
DE, DOTCLK G1 G3 B G R TFT-LCD Panel (480´272xRGB) G2 G4 (Scan Direction) G271 D-IC G272 User Connector 45 Pin (VDD) Input Power VLED1+ Input Data (RGB 8bit,) Input Signal (DE, CLK, PON) VLED1－ GND Ver 1.0 Oc.
