LB043WQ2-TD08 - TFT LCD

LB043WQ2-TD08 Datasheet Preview — Preview of LB043WQ2-TD08 PDF

Datasheet Details

Part number	LB043WQ2-TD08
Manufacturer	LG
File Size	521.27 KB
Description	TFT LCD
Datasheet	LB043WQ2-TD08-LG.pdf

LB043WQ2-TD08 Product details

Description

Interface Connection Absolute Maximum Ratings Electrical Characteristics Optical Characteristics Mechanical Characteristics Color Input Data Reference Reliability Test Outline Dimension International Standard Packing Precautions Page 3 4 6 8 9 15 18 19 20 21 23 24 27 Ver 1.2 Sep.29. 2009 2 / 28 LB043WQ2 Liquid Crystal Display Product Specification RECORD OF REVISIONS Revision No Revision Date Page Description Note Ver 1.2 Sep.29. 2009 3 / 28 LB043WQ2 Liquid Crystal Display Product

Features

High brightness & contrast ratio.
Wide viewing angle.
WQVGA(480X272 pixels) resolution.
8 bits color depth.
T-Con & power block integrated in D-IC.
Low power consumption.
DE (Data Enable) only mode.
DE, DOTCLK B G R TFT-LCD PANEL (480×272xRGB) (SCAN.
