LTV-480P-TA1 OPTOCOUPLER

The LTV-480 series fast speed photocoupler contains a AlGaAs LED and photo detector with built-in Schmitt trigger to provide logic-compatible waveforms, eliminating the need for additional wave shaping. The totem pole output eliminates the need for a pull up resistor and allows for direct drive Int.

LTV-480P-TA1 Features

* Positive output type (totem pole output)

* Truth Table Guaranteed: VCC from 4.5V to 30V

* Performance Specified for Common IPM Applications Over Industrial Temperature Range.

* Short Maximum Propagation Delays

* Minimized Pulse Width Distortion (PWD)

* Very High Common Mode

LTV-480W-LITE-ON.pdf

LTV-480P-TA1 Datasheet Preview — This datasheet PDF includes multiple part numbers: LTV-480P-TA1, LTV-480W-LITE. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

LTV-480P-TA1, LTV-480W-LITE

Manufacturer:

LITE-ON

File Size:

718.61 KB

Description:

Optocoupler.

Note:

This datasheet PDF includes multiple part numbers: LTV-480P-TA1, LTV-480W-LITE.
Please refer to the document for exact specifications by model.
