LESDA14V2LT1G

Dual transil array

LESDA14V2LT1G Features

* z z z z 2 Unidirectional Transil functions Low leakage current: IR max< 20 μA at VBR 3 00W peak pulse power(8/20μs) High ESD protection level: up to 25 kV Benefits z z z High ESD protection level up to 25 kV. High integration. Suitable for high density boards. Complies with the following standards

LESDA14V2LT1G General Description

The LESDAxxxLT1G is a dual monolithic voltage suppressor designed to protect components which are connected to data and transmission lines against ESD. It clamps the voltage just above the logic level supply for positive transients, and to a diode drop below ground for negative transients. It can al.

LESDA14V2LT1G Datasheet (597.34 KB)

Preview of LESDA14V2LT1G PDF

Datasheet Details

Part number:

LESDA14V2LT1G

Manufacturer:

Leshan Radio Company

File Size:

597.34 KB

Description:

Dual transil array.
