LTC1731-8.4 Lithium-Ion Linear Battery Charger Controller

Linear Technology

Description

LTC1731-8.2/LTC1731-8.4 Lithium-Ion Linear Battery Charger Controller .

📥 Download Datasheet

LTC1731-8.4 Datasheet Preview — Preview of LTC1731-8.4 PDF

Datasheet Specifications

Part number: LTC1731-8.4
Manufacturer: Linear Technology
File Size: 146.78 KB
Datasheet: LTC1731-8.4-LinearTechnology.pdf
Description: Lithium-Ion Linear Battery Charger Controller

Features

* s s s s s s s DESCRIPTIO s s Complete Linear Charger Controller for 2-Cell Lithium-Ion Batteries 1% Voltage Accuracy Programmable Charge Current C/10 Charge Current Detection Output Programmable Charge Termination Timer Space Saving 8-Pin MSOP Package Automatic Sleep Mode When Input Supply is Rem

Applications

* Information section). The DRV pin is internally clamped to 6.5V below VCC. VCC (Pin 7): Input Supply Voltage. VCC ranges from 8.8V to 12V when charging. If VCC drops below VBAT + 54mV, for example when the input supply is disconnected, then the IC enters sleep mode with ICC < 30µA. Bypass this pin w
