LTC3861-1 - Multiphase Step-Down Voltage Mode DC/DC Controller

📥 Download Datasheet

Preview of LTC3861-1 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number LTC3861-1
Manufacturer Linear Technology
File Size 1.18 MB
Description Multiphase Step-Down Voltage Mode DC/DC Controller
Datasheet download datasheet LTC3861-1-LinearTechnology.pdf

LTC3861-1 Product details

Description

n Operates with Power Blocks, DrMOS or External Gate Drivers and MOSFETs n Constant-Frequency Voltage Mode Control with Accurate Current Sharing n ±0.75% 0.6V Voltage Reference n Differential Remote Output Voltage Sense Amplifier n Multiphase Capability Up to 12-Phase Operation n Programmable Current Limit n Safely Powers a Prebiased Load n Programmable or PLL-Synchronizable Switching Frequency Up to 2.25MHz n Lossless Current Sensing Using Inductor DCR or Precision Current Sen
