LPA2162 ADSL Line LPAnsformers

ADSL Line LPAnsformers For use with Analog Devices AD20msp930 ADSL Chipset (CenLPAl Office) For RoHS part add suffix NL RoHS NL peak solder rating 235 Link-PP Int’l Technology Part Number LPA2162 Mounting SMT Electrical Specification @ 25 - Operating Temperature -40 to + 85 Application CO Turns Ratio (10-7):(1-4) (#2%) 1:1.1 OCL @ 10 KHz, 0.1V (mH MIN) (1-4)with2-3shorted 2.03 (10-7)with 8-9shorted 1.75 Leakage Inductance @100KHz,0.1V(.

LPA2162-Link-PP.pdf

LPA2162 Datasheet Preview — This datasheet PDF includes multiple part numbers: LPA2162, LPA2162-Link. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

LPA2162, LPA2162-Link

Manufacturer:

Link-PP

File Size:

146.18 KB

Description:

Adsl line lpansformers.

Note:

This datasheet PDF includes multiple part numbers: LPA2162, LPA2162-Link.
Please refer to the document for exact specifications by model.
