LTE-S3201, LTE-S3201-Lite IR Emitter and Detector

LTE-S3201 Description

IR Emitter and Detector Product Data Sheet LTE-S3201 Spec No.: DS50-2010-0008 Effective Date: 05/10/2012 Revision: B LITE-ON DCC RELEASE BNS-OD-FC001/.

LTE-S3201 Features

* Meet ROHS, Green Product.
* Package In 8mm Tape On 7" Diameter Reels.
* Compatible With Automatic Placement Equipment.
* Compatible With Infrared Reflow Solder Process.
* EIA STD package. REV. B MAY 2012 Package Dimensions Notes: 1. All dimensions are in millimeters (inches)

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: LTE-S3201, LTE-S3201-Lite. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
LTE-S3201, LTE-S3201-Lite
Manufacturer
Lite-On Technology
File Size
610.52 KB
Datasheet
LTE-S3201-Lite-OnTechnology.pdf
Description
IR Emitter and Detector
Note
This datasheet PDF includes multiple part numbers: LTE-S3201, LTE-S3201-Lite.
Please refer to the document for exact specifications by model.
