Datasheet Details
Part number:
SZ1SMB43AT3G, SZ1SMB5.0AT3G
Manufacturer:
File Size:
823.74 KB
Description:
Tvs diodes.
Note:
This datasheet PDF includes multiple part numbers: SZ1SMB43AT3G, SZ1SMB5.0AT3G.
Please refer to the document for exact specifications by model.
SZ1SMB43AT3G, SZ1SMB5.0AT3G, TVS Diodes
The SZ1SMB series is designed to protect voltage sensitive components from high voltage, high energy transients.
They have excellent clamping and high surge capability, as well as fast response time.
The SZ1SMB series is supplied in cost-effective, highly reliable DO-214AA package and it is ideal fo
SZ1SMB43AT3G Features
* & Benefits
* Zener Transient Overvoltage Suppressors
* Working Peak Reverse Voltage Range
* 5.0 V to 170 V for uni-directional, and 10 V to 78 V for bi-directional
* Standard Avalanche Breakdown Voltage Range
* 6.4 V to 209 V for unidirectional, 11.1 V to 95.80 V for bi-di
