MP2361DK

1.4MHz Step-Down Converter

MP2361DK Features

* 2A Output Current

* 0.18Ω Internal Power MOSFET Switch

* Stable with Low ESR Output Ceramic Capacitors

* 90% Efficiency

* 20μA Shutdown Mode

* Fixed 1.4MHz Frequency

* Thermal Shutdown

* Cycle-by-Cycle Over Current Protection

* Wide 4.75V to 23V Operating Input

MP2361DK General Description

The MP2361 is a monolithic step-down switch mode converter with a built-in internal power MOSFET. It achieves 2A continuous output current over a wide input supply range with excellent load and line regulation. Current mode operation provides fast transient response and eases loop stabilization. Fau.

MP2361DK Datasheet (484.41 KB)

Preview of MP2361DK PDF

Datasheet Details

Part number:

MP2361DK

Manufacturer:

MPS

File Size:

484.41 KB

Description:

1.4mhz step-down converter.
