MP2365DN, MP2365 - 1.4MHz Step-Down Converter

MPS

The MP2365DN by MPS is a 1.4MHz Step-Down Converter. Below is the official datasheet preview.

📥 Download Datasheet

MP2365DN 1.4MHz Step-Down Converter by MPS - Datasheet Preview — Official preview page of the MP2365DN 1.4MHz Step-Down Converter datasheet (MPS).

Datasheet Details

Part number	MP2365DN, MP2365
Manufacturer	MPS
File Size	509.71 KB
Description	1.4MHz Step-Down Converter
Datasheet	MP2365-MPS.pdf
Note	This datasheet PDF includes multiple part numbers: MP2365DN, MP2365. Please refer to the document for exact specifications by model.
Additional preview pages of the MP2365DN datasheet.

MP2365DN Product details

Description

The MP2365 is a 1.4MHz step-down regulator with a built-in power MOSFET.

Features

3A Continuous Output Current, 4A Peak Output Current.
Programmable Soft-Start.
100mΩ Internal Power MOSFET Switch.
Stable with Low ESR Output Ceramic Capacitors.
Up to 91% Efficiency.
20μA Shutdown Mode.
Fixed 1.4MHz Frequency.
Thermal Shutdown.
Cycle-by-Cycle Over Current Protection.
Wide 4.75V to 28V Operating Input Range.
Output is Adjustable From 0.92V to 21V.
Under Voltage Lockout.
