MP3393 - 8-String Step-Up White LED Driver

MPS

📥 Download Datasheet

MP3393 Datasheet Preview — Preview of MP3393 PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number: MP3393
Manufacturer: MPS
File Size: 508.49 KB
Datasheet: MP3393-MPS.pdf
Description: 8-String Step-Up White LED Driver

MP3393 Product details

Description

The MP3393 is a step-up controller with 8 current channel sources designed to power WLED backlights for large LCD panels.

Features

9V-to-32V Input Voltage Range.
Drives 8 Channels of LED strings.
Internal Constant-Current Control.
Maximum Channel Current Over 350mA.
1.2% Current Matching Accuracy Between Strings.
Programmable Switching Frequency.
Analog Dimming and External PWM Dimming.
Open and Short LED Protection.
Programmable Over-Voltage Protection.
Fault Output Flag.
Thermal Shutdown.
Extendable LED Channels th.
