MBQ40T65FESC Datasheet, Igbt, MagnaChip

MBQ40T65FESC Features

• Igbt
• High Speed Switching & Low Power Loss
• VCE(sat) = 1.95V @ IC = 40A
• Eoff = 0.3mJ @ TC = 25°C
• High Input Impedance
• trr = 80ns (typ.) @diF

PDF File Details

Part number:

MBQ40T65FESC

Manufacturer:

MagnaChip

File Size:

1.84MB

Download:

📄 Datasheet

Description:

Igbt. This IGBT is produced using advanced MagnaChip’s Field Stop Trench IGBT Technology, which provides high switching series and excellen

MBQ40T65FESC Application

• Applications TO-247 MBQ40T65FESC 650V Field Stop IGBT Features
• High Speed Switching & Low Power Loss
• VCE(sat) = 1.95V @ IC =
