MAX2538 Datasheet, Lan/mixers, Maxim Integrated Products

MAX2538 Features

• Lan/mixers
• Eliminate Up to 35 External Components
• Low LNA Noise Figure PCS: 1.2dB Cellular: 0.9dB GPS: 1.0dB
• No External GPS VCO Required
• No Interstage GPS

PDF File Details

Part number:

MAX2538

Manufacturer:

Maxim Integrated ↗ Products

File Size:

653.05kb

Download:

📄 Datasheet

Description:

Quadruple-mode pcs/cellular/gps lan/mixers. The MAX2351/MAX2354/MAX2358/MAX2359/MAX2530/ MAX2531/MAX2537/MAX2538 family of single- and multiband LNA/mixer ICs is optimized for C

MAX2538 Application

• Applications in both cellular and PCS bands. In addition, the MAX2530/MAX2531/MAX2537/MAX2538 ICs feature a GPS LNA/mixer signal path for E911 and t
