LS124 General Purpose

LS124 MONOLITHIC DUAL NPN TRANSISTOR Linear Systems replaces discontinued Intersil IT124 The LS124 is a monolithic pair of Super-Beta NPN transistors mounted in a single P-DIP package. The monolithic dual chip design reduces parasitics and gives better performance while ensuring extremely tight matching. The LS124 is a direct replacement for discontinued Intersil IT124. The 8 Pin P-DIP provides ease of manufacturing, and the symmetrical pinout prevents improper orientation. (See Packaging Infor.

LS124 Features

* FEATURES Direct Replacement for INTERSIL LS124 HIGH GAIN LOW OUTPUT CAPACITANCE VBE tracking ABSOLUTE MAXIMUM RATINGS 1 @ 25°C (unless otherwise noted) Maximum Temperatures Storage Temperature Operating Junction Temperature Maximum Power Dissipation Continuous Power Dissipa

LS124 Datasheet (287.28 KB)

LS124 Datasheet Preview — Preview of LS124 PDF

Datasheet Details

Part number:

LS124

Manufacturer:

Micross

File Size:

287.28 KB

Description:

General purpose.
