LS130 General Purpose

LS130 MONOLITHIC DUAL PNP TRANSISTOR Linear Systems replaces discontinued Intersil IT130 The LS130 is a monolithic pair of PNP transistors mounted in a single P-DIP package. The monolithic dual chip design reduces parasitics and gives better performance while ensuring extremely tight matching. The LS130 is a direct replacement for discontinued Intersil IT130. The 8 Pin P-DIP provides ease of manufacturing, and the symmetrical pinout prevents improper orientation. (See Packaging Information). LS.

LS130 Features

* High hfe at low current

* Tight matching Tight VBE tracking

* Low Output Capacitance FEATURES Direct Replacement for INTERSIL IT130 HIGH hFE @ LOW CURRENT OUTPUT CAPACITANCE VBE tracking ABSOLUTE MAXIMUM RATINGS 1 @ 25°C (unless otherwise noted) Maximum Temperatures Stor

LS130 Datasheet (287.21 KB)

LS130 Datasheet Preview — Preview of LS130 PDF

Datasheet Details

Part number:

LS130

Manufacturer:

Micross

File Size:

287.21 KB

Description:

General purpose.
