5340-64BGS17F

2.54mm (.100) Pitch QF-50 / Right Angle / Dual Row with Eject Levers / Shrouded Header / 64 Circuits

5340-64BGS17F General Description

0039533647 Active 2.54mm (.100") Pitch QF-50™, Right Angle, Dual Row with Eject Levers, Shrouded Header, 64 Circuits Documents: 3D Model Drawing (PDF) RoHS Certificate of Compliance (PDF) General Product Family Series Comments Component Type Glow-Wire Compliant Product Name Ribbon Cable / Wire .

5340-64BGS17F Datasheet (189.57 KB)

Preview of 5340-64BGS17F PDF

Datasheet Details

Part number:

5340-64BGS17F

Manufacturer:

Molex Electronics

File Size:

189.57 KB

Description:

2.54mm (.100) pitch qf-50 / right angle / dual row with eject levers / shrouded header / 64 circuits.
