AXK6F60x45 Datasheet - NAIS

AXK6F60x45 (AXKxF Series) Narroe Pitch Connectors

AXKⅪF NARROW-PITCH CONNECTORS FOR PC BOARDS 2. Unique bellows-type contacts Our unique bellows-type contacts resist mating stress and offer high contact reliability. The bellows contacts comprise thin formed sheet metal. They offer reliable contact since a rounded coner, instead of a sharp edge, is used for contact. Round corner Rounde corner makes makescontact. contact. NARROW PITCH (0.5mm) CONNECTORS P5KF 5. Construction resistant to solder lift-off The construction provid.

AXK6F60x45 Features

* 1. Low profile of 1.5mm Low profiles of 1.5mm, 2.0mm and 2.5mm are realized. They allow products to be slimmer. 4. Mating length 0.55mm While achieving a low profile of 1.5mm between PCBs, the effective mating length has been extended to ensure that there is some latitude in the mating. SPECIFICAT

AXK6F60x45 Datasheet (281.20 KB)
