HA-1211 - Crystal Clock Oscillators

HA-1211 Description

CRYSTAL CLOCK OSCILLATORS TTL Compatible Enable/Disable HA-1210 Series Data Sheet 8820B Rev.L .
The HA-1210 Series of quartz crystal oscillators provide enable/disable 3-state TTL compatible signals for bus connected systems.

HA-1211 Features

* Wide frequency range
* 0.5MHz to 36MHz
* User specified tolerance available
* Will withstand vapor phase temperatures of 253°C for 4 minutes maximum
* Space-saving alternative to discrete component oscillators
* High shock resistance, to 3000g

📥 Download Datasheet

Preview of HA-1211 PDF
datasheet Preview Page 2

Datasheet Details

Part number
HA-1211
Manufacturer
NEL Frequency
File Size
345.91 KB
Datasheet
HA-1211_NELFrequency.pdf
Description
Crystal Clock Oscillators
