BGY1816, UHF amplifier

The BGY1816 is a three-stage UHF amplifier module in a SOT365A package with a plastic cap.

It consists of three NPN silicon planar transistor dies mounted together with matching and bias circuit components on a metallized ceramic AlN substrate.

handbook, halfpage BGY1816 PINNING - SOT365A PIN 1 2 3
