BGY68 Datasheet - NXP

CATV amplifier

BGY68 General Description

Hybrid high dynamic range amplifier module in a SOT115J package operating at a voltage supply of 24 V (DC). PINNING - SOT115J PIN 1 2 3 5 7 8 9 input common common +VB common common output BGY68 DESCRIPTION handbook, halfpage 1 2 3 8 5 7 9 Side view MSA319 Fig.1 Simplified outline. QUICK .

BGY68 Datasheet (51.58 KB)

BGY68 Datasheet Preview — Preview of BGY68 PDF

Datasheet Details

Part number:

BGY68

Manufacturer:

NXP ↗

File Size:

51.58 KB

Description:

Catv amplifier.
DISCRETE SEMICONDUCTORS DATA SHEET BGY68 CATV amplifier module Product speciﬁcation Supersedes data of September 1995 File under Discrete Semiconduc.
