BSS61 - PNP transistors

Datasheet Summary

Description

DESCRIPTION PNP Darlington transistor in a TO-39 metal package.

NPN complements: BSS51 and BSS52.

Fig.1 Simplified outline (TO-39) and symbol.

Features

  • High current (max. 1 A).
  • Low voltage (max. 80 V).
  • Integrated diode and resistor.
