MC07XS6517DEK Description
NXP Semiconductors Data sheet: Technical Data 17 mOhm and 7.0 mOhm high-side switches The 12XS6 is the latest SMARTMOS achievement in automotive light.
MC07XS6517DEK Features
* Quad or penta high-side switches with high transient capability
* 16-bit 5.0 MHz SPI control of overcurrent profiles, channel control including
PWM duty cycles, output on and off open load detections, thermal shutdown and prewarning, and fault reporting
* Output current mon
MC07XS6517DEK Applications
* Low-voltage automotive exterior lighting
* Halogen lamps
* Incandescent bulbs
* Light-emitting diodes (LEDs)
* HID Xenon ballasts
VBAT
VBAT VCC 5.0 V
Regulator
GND
VCC
Main MCU
GND
SO CSB SCLK
SI
RSTB
CLK A/D1
TRG1 PORT
PORT PORT PORT
PORT A/D2
07XS6517
